Generic1
This inline manual switch goes between the power source and the device to add a convenient and reliable point of power control
Specifications
- 5.5mm x 2.1mm barrel
- 26cm cable
What's in the box?
1 x switch barrel connection
Specifications:
Comprehensive error: 0.05% F.S
Rated output temperature drift: ≤ 0.15% F.S / 10 ℃
Output Sensitivity: 1.0 ± 0.1 mV / V
Zero drift: 0.05% F.S (1 minute)
Zero point temperature drift: 0.2% F.S / 10 ° C
Zero output: ± 0.1 mV / V
Input impedance: 1000 ± 50Ω
Output impedance: 1000 ± 50Ω
Overload capacity: 150% F.S
Recommended excitation voltage: 5-10V
Operating temperature range: -10 ~ 50 ℃
Application:
For high-precision small-scale weighing for micro-automatic testing equipment, micro-weighing equipment, pushing and pulling equipment, pull pressure test
Red: E
Black: E-
White: A-
Green: A
What's in the box?
1 x Weighing Sensor Load Cell
1 x HX711 Module
Resources:
Building a Raspberry Pi weight scale
Python Library
Building an Arduino weight scale
It cleans better than conventional sponges.
- Colour : Gold
- Size : 70mm x 69mm x 69mm
1 x Iron Tip Cleaner
Resources
Introduction to soldering
Video: How to solder properly
The secrets to good soldering
A switching power supply is one of the two major types of power supply design utilized in electronics products. These power supplies are characterized by the use of precise switching that allows for designs to accommodate DC to DC, DC to AC, AC to DC and frequency conversions.
Specifications
- Input Voltage: AC110V/220V±15%
- Ouput Voltage: DC 12V
- Output Current:5A
- Shell Material: Metal case
- Safety Compliance: FCC / CE
- High price-effective, reliability with industry standards
- Built-in over voltage, over current, and short circuit protection
- Working Temperature: 0~40C
- Storage Temperature: -20~60C
- Ambient Humidity: 0~95% Non-Condensation
Features
- Switch power supply, convert AC 110V/240V to 12V
- Wide input voltage range, steady and precise output voltage.
- Shortage protection, overload protection over voltage protection.
- Widely used as the power adapter for Led strip, LED display, billboard, industrial equipment, etc.
Please note: INDOOR USE ONLY!
What's in the box?
1 x 12V 5A power supply
Features
Easy to use.
Operating Voltage: DC12V
Maximum Load: 10A
Operating Frequency: 433MHZ
Receiver Sensitivity: -100dBm
Encoding Type: learning code
Board Size: Approx. 5.3x3.1cm/ 2.09x1.22"
Relay rating
- 10A 250VAC
- 10A 125VAC
- 10A 30VDC
- 10A 28VDC
To check compatibility of a new remote with the receiver. Simply press the button on the remote, if the receiver flashes, but does not Triger the relay. The remote will be compatible, and you can start the programing process
To add a remote, press the button on receiver momentarily. The red light will come on. Then press the button on the remote that you want to program in. The red light will start flashing. After 4 flashes in will stop, and the button will be programmed in.
For the setting to take effect, the board needs to be disconnected from it’s power supply. The bellow settings will be done to the 3 headers and bridge pin on the receiver board, above the push button.
- With the header removed, the On button will switch the relay on, and the off button will in turn switch the relay off.
- With the header on Pin 1-2. Both Buttons will become momentary. And only hold the relay in place as long as they are pressed in.
- With the header on Pin 2-3. Each button will be able to switch the relay on and off individually. You will however not be able to switch the button off with the “off” button, if you switched it on with the “on” button. And vise versa.
What's in the box?
1 x Learning Code Receiver Relay
1 x Remote Control
Features
- Chip: FT232RL
- Draw out all signal port of FT232RL chip
- RXD / TXD transceiver communication indicator
- USB power supply, can choose 5V or 3.3V, set by jumper
- With over current protection, using 500mA self-restore fuse
- Pin definition: DTR, RXD, TX, VCC, CTS, GND
- Pitch: 2.54mm
- Size: 36 x 18mm (L x W)
- Interface: Mini USB
The USB to TTL serial adapter is based on the high quality and very popular FTDI FT232RL chipset and is an excellent way to connect TTL serial devices to a PC through a USB port.
This USB to TTL serial adapter is ideal for many uses, including:
- Programming microprocessors such as ARM, AVR, etc
- Working with computing hardware such as routers and switches
- Serial communication with many devices such as GPS devices
- Serial terminals on devices like the Raspberry Pi
- Unlike most USB to TTL serial adapters, this adapter supports both 5V AND 3.3V operation! Simply set the jumper as required to choose between 5V and 3.3V as labelled on the board.
The adapter comes with a right-angle connector fitted allowing you to use it straight away. If you need to access any of the other inputs or outputs of the FT232RL, all the useful signals are provided as through-hole solder pads - ideal for use with straight headers into a breadboard, for example.
What's in the box?
1 x FT232RL USB to serial converter module
Refillable flux pens for all your rework needs including no-clean, rosin and water soluble. Liquid Solder Flux Pen is used to clean PCB track and legs or pins of electronic components while soldering.
Specifications
- No-Clean Flux
- Net volume: 10ml
- Shelf life @ 25 degree C: 2 year
- Push the pen tip to start the flux flow
- Keep the pen cap on when not in use
What's in the box?
1 x flux pen
Warning
- When coming into contact with skin, please wash the area immediately to avoid skin irritation.
- Do not consume.
- Please store in a safe location where children can not reach it.
Resources
Introduction to soldering
Video: How to solder properly
The secrets to good soldering
This listing includes: 10 pairs of MC4 parallel connectors for 3 solar panels. (FFFM and MMMF)
Used for connecting solar panels in series or parallel, quick and reliable connection of the solar cables to the photovoltaic system.
Application
It can be used for connecting 3 solar panels in parallel.
Advantage
1). Easy to use
2). TUV certification
Specifications
- Rated Voltage: (VDC)1000
- Rated Current: (A)40A
- Low Ambient Temperature: (°C)-40°C
- Upper Ambient Temperature: (°C) 90°C
- Degree of Protection (IP Code): IP67
- Contact Material: Copper
- Insulation Material: PPO PA
- Certification: TUV
- Connection resistance: <= 1m Ω
- Insertion force: <=60N
- Withdraw force: >=60N
- Flame class: UL94-VO
What's in the box?
1 x 3M1F connector
1 x 3F1M connector
They are used in stand-alone ("off-grid") systems to prevent batteries from discharging through the solar cells at night.
Specifications
- 15A
- 45V
What's in the box?
1 x Schottky Diode
Resources
The MLX90615 is an Infra Red thermometer for non contact temperature measurements. Both the IR sensitive
thermopile detector chip and the signal conditioning chip are integrated in the same TO-46 can package.
Thanks to its low noise amplifier, 16-bit ADC and powerful DSP unit, a high accuracy and resolution of the
thermometer is achieved. The thermometer is factory calibrated with the digital SMBus compatible
Features
- Small size, low cost
- Easy to integrate
- Factory calibrated in wide temperature range: -40…85C for sensor temperature and -40…115C for object temperature
- High accuracy of 0.5C over wide temperature range (0... 50C for both TA and TO )
- High (medical) accuracy calibration
- Measurement resolution of 0.02C
- SMBus compatible digital interface
- Power saving mode
- Customizable PWM output for continuous reading
- Embedded emissivity compensation
- 3V supply voltage
Datasheets available at https://github.com/arduinolearning/Datasheets/blob/master/MLX90614.pdf
The reed switch is an electrical switch operated by a magnetic field. In it's most basic form, the switch consists of a flexible ferromagnetic metal contacts inside a sealed glass tube. When a magnet is brought close to the 'reeds', the reeds move so that they come into contact, closing the switch.
Best used to alert when unauthorized entry is made.
2. Simple installation
3. The metals electroplates outer shell, double-loop circuit design, performance stable.
4. Circuit is open when magnet is near the switch.
5. Special use for metal doors, anti-magnetic interference design.
Rated Voltage: 100V
Contact Type: Normally Closed
Size: 10.6 x 3.8 x 1cm/ 4.2" x 0.15" x 0.4" (L x W x T)
Cord Length: approx.45cm/ 17.7"
A great charge control module for smaller sized solar projects
Features
- PWM controller,Long standby time
- Three stage charging can effectively improve battery life.
- Easy installation and easy operation
- LED indicator, battery power display
- Manual adjustable discharge mode
Specifications
- Charging mode: PWM
- System current:5A/10A
- Voltage:6V/12V
- Interior input power:≤30W/≤60W
- Overload, short circuit protection
: 1.5 times rated current, five minutes off; Five minutes to recover - Rated voltage no-load current:≤6mA
What's in the box?
1 x Solar controller
1 x User manual
The case has slots to access the USB port, buttons and JST connectors. It’s especially designed to allow the on-board LED matrix to be viewed when lighted up. It’s aimed to create a more interesting programming environment for children, getting rid of the past boring programming life.
Features:
Protect your micro:bit
Specifications:
- Product Size: 56mm x 45mm
- Thickness: 12mm
Note:
Micro:bit control board is not included
What's in the box?
1 x Micro:bit Silicone Protective case for V1
Features
- Comparative output, clean signal, good waveform, strong driving ability, more than 15mA.
- Working voltage: 3.3V to 5V
- Output form: digital switch output (0 and 1)
- Equipped with fixed screw hole, easy to install
- PCB board size: 32mm x 14mm
- Uses the LM393 wide voltage comparator
When the VCC and GND are connected, the power indicator will light up.
Put the module on the desktop, adjust the blue potentiometer on the board until the on-board switch indicator lights up, and then slightly turn back the potentiometer untill the indicator light turns off. Hit the desktop with your hand so the vibration shocks the sensor, the indicator light will go on. Vibration stops, indicator light will turn off.
Raspberry Pi Python example
LEARN ABOUT ELECTRICITY – Provide a fun learning experience for inquisitive minds
TB6600 is an easy-to-use professional stepper motor driver, which could control a two-phase stepping motor. It is compatible with Arduino and other microcontrollers that can output a 5V digital pulse signal. TB6600 arduino stepper motor driver has a wide range power input, 9~42VDC power supply. And it is able to output 4A peak current, which is enough for the most of stepper motors.
The stepper driver supports speed and direction control. You can set its micro step and output current with 6 DIP switch. There are 7 kinds of micro steps (1, 2 / A, 2 / B, 4, 8, 16, 32) and 8 kinds of current control (0.5A, 1A, 1.5A, 2A, 2.5A, 2.8A, 3.0A, 3.5A) in all. And all signal terminals adopt high-speed optocoupler isolation, enhancing its anti-high-frequency interference ability.
As a professional device, it is able to drive 57, 42-type two-phase, four-phase, hybrid stepper motor.
Features
- 9V-40V DC power supply
- H-bridge bipolar constant phase flow driver
- The maximum output current is 4.0A (eight optional)
- Up to 32 segments of six kinds of sub-modes available
- Input signal high-speed photoelectric isolation
- Standard common anode single pulse interface
- Offline keep function
- Semi-enclosed chassis can adapt to a more demanding environment
- Provide energy saving semi-automatic current lock function
- Built-in thermal protection and over-current protection
Specifications
- Voltage: up to 50V
- ON resistance (upper lower) = 0.4 Ω
- Forward and reverse rotation control
- 5 kinds of sub-modes selectable (1/1, 1/2, 1/4, 1/8, 1/16 step)
- Output current: IOUT = 5.0A (peak within 100ms)
- Rated output: IOUT = 4.5 A
- Input pull-down resistor: 100 KΩ
- Current output alarm pin: Ialert = 1mA
- Monitor output pin (MO): Imo = 1mA
- With reset and enable pins
- With a standby function.
- Breaking the traditional single-supply
- Built-in thermal protection (TSD) circuit
- Built-in voltage protection (UVLO) circuit
- Built-in over current detection (ISD), the circuit
Note:
This driver is the upgraded version TB6600, heightening segment to 32 subdivision, suitable for high segmentation applications.
For step motor: 42, 57, 86 type 2 phase 4 phase (4 / 6 / 8 line)
What's in the box?
1 x TB6600 Stepper Motor Driver Controller
Resources
https://danielwilczak101.medium.com/control-a-stepper-motor-using-python-and-a-raspberry-pi-11f67d5a8d6d
https://www.instructables.com/Raspberry-Pi-Python-and-a-TB6600-Stepper-Motor-Dri/
The LiitoKala Lii-402 Smart Charger for Lithium Ion and NiMH batteries is the perfect bench mate to keep your radios, robotics and flashlights running at peak efficiency. In a sea of endless chargers for sale, we have found one that will meet and exceed the needs of many consumers.
Specifications
Product name: Liitokala Lii-402 Micro USB 4Slots Battery Charger
Input : Micro USB DC 5V/2A
Output
- 1.42V
- 4.2V±0.05V
- 3.65±0.05V
- 4.35±0.05V
Current
- 2000mA*1
- 1000mA*2
- 700mA*3
- 500mA*4
Constant voltage, cut-off current: less than 100mAh
Standby current: less than 15mAh
Compatible with
Ni-MH/Cd
AA/AAA/A/SC Sizes
3.7V Li-ion battery including
26650,22650,26500,18650,18490,17670,17500,16340,14500,10440
Size: 112mm x 90mm x 30mm (L x W x H)
Weight: 150 grams (incl. micro cable)
USB Output function
1. 0pen-circuit voltage of USB output : 4.9-5.3V; and the 4th slot is fixed for the USB discharge power source
2. Output current: 1000mAh
3. Open circuit current: <1mAh
4. The corresponding voltage is 4.75-5.25V under 1000mAh current
5. Cut-off voltage for discharge protection: 3.0±0.1V
1 x Liitokala Lii-402 Micro USB 4Slots Battery Charger
1 x USB micro B male to USB A male Cable
You will also need.....
power supply for this charger
The TB6560 stepper motor control circuit is the most commonly used current circuit, which can control a 2 phase motor (10 – 35VDC) with a maximum output of 3A.
Specifications
- Size: 75mm x 50mm x 35mm (L x W x H)
- Rated maximum output: ± 3A, peak 3.5A
- Working voltage: DC 10V-35V
- Recommended to use a switching power supply: DC24V power supply
- Subdivision: whole step, half-step, step 1/8, 1/16 step, a maximum of 16
- Subdivisions.
Features
- Using the Toshiba TB6560AHQ new original chip with low voltage shutdown, overheating stop and over current protection circuit to ensure optimal performance.
- For two-phase within 42, 57 stepping 3A / four-phase / of line four / six-wire stepper motor, and is not suitable for more than 3A stepper motor.
- Automatic half current function.
- 6N137 high-speed optical coupling, guarantee high speed without losing step.
What's in the box?
1 x TB6560 1 axis driver board
4. This is an entry level measuring solution. Do not expect 100% accuracy.
Product Type | PZEM-022 |
Accuracy | 1.0 grade |
Display Size | 51mm x 30mm |
Product Size | 89.6mm x 49.6mm x 24.3mm |
Weight | 150g(with split CT) |
Test Range | 1. Voltage: 80~260V 5. Frequency: 45~65Hz 6. Power factor: 0~1PF |
Function | 1. Electrical parameter measurement function (voltage, current, active power, energy, frequency, power factor) 2. Overload alarm function (over power alarm threshold, backlight and power flashing to alarm). 3. Power alarm threshold preset function (can set power alarm threshold). 4. The energy can be reset use the key. 5. Store data when power off. 6. Large-screen LCD 7. Backlight function. |
What's in the box?
1 x CT
Resources
FAQ
Why is the test data wrong? Voltage * Current = Power, But power is less than the actual test voltage * Current, Why is that?
Answer: There are three types of power:
Active Power (P represents / unit W)
Reactive power (Q represents / unit Var)
Apparent power (S represents / unit VA)
Here we only talk about Active Power, for others, please google it:
P = U * I * cosφ, cosφ it represents the power factor, purely resistive load (Such as incandescent, heater, etc.) the power factor is generally close to 1,Between the inductive and capacitive load load power factor 0-1. So purely resistive load test time, P is substantially equal to or close to U * I. When Inductive or capacitive load test (Such as refrigerators, washing machines, televisions, computers, etc.) P<U*I, As for how much to keep the power factor related to the specific, Different for each appliance power factor.
Know how much rain you got overnight with this digital wireless rain station
Features
- Outdoor wireless sensor (range up to 100 meter)
- Detail display of rainfall data in 1hour, 24hour, week, month
and total since last reset(user selectable in inch or mm) - Indoor and outdoor temperature (°F to °C)
- Time and date with manual setting option
- 12 /24 hour time mode
- Calendar
- Time zone setting
- Time alarm
- Free standing
Specifications
- Rainfall display range: 0 to 19,999mm
- Outdoor temperature range: -40 ~ 65°C (-40°F to 149°F)
- Indoor temperature range: -9.9 ~ 60°C (-15.8°F to 176°F)
- Temperature accuracy: ±1.0°C5) Power requirements:
a) Receiver: 2 x "AA" alkaline batteries (not included)
b) Rain gauge: 2 x "AAA" alkaline batteries (not included) - Transmission range: up to 100meters( 330feet)
- Transmission frequency: 433MHz
What's in the box?
1 x Rain Gauge
1 x Receiver
1 x User Manual
2 x Screws
